LC-LC Single Mode Fiber Jumper Cable, 9/125μm UPC Duplex SMF SFP Fiber Patch ...

Câble de raccordement en fibre optique monomode LC-LC, câble de raccordement SFP en fibre optique SMF duplex 9/125 μm UPC pour commutateur de centre de données

Name: Câble de raccordement en fibre optique monomode LC-LC, câble de raccordement SFP en fibre optique SMF duplex 9/125 μm UPC pour commutateur de centre de données
Brand: SYY Tech

LC to LC single-mode duplex fiber jumper cable with small form factor LC connectors, precision ceramic ferrules, low insertion loss. Designed for SFP/SFP+ transceivers and high-density cabling. Ideal for data center, core switch and 10G network. OEM custom service supported.

Request a Quote

Enter the quantity you need and add to your quote list for pricing inquiries.

Quantité :

Categories: Câbles et modules à fibre optique

Description

This LC-LC single-mode fiber jumper cable is a high-density optical connectivity solution designed for SFP, SFP+ optical modules and high-density fiber distribution systems. It is widely used in data center top-of-rack switches, core routers, 10G/25G Ethernet networks, storage area networks (SAN) and telecom transmission equipment.

Adopting standard 9/125μm single-mode fiber and mini LC connectors with precision zirconia ceramic ferrules, it provides excellent optical performance with ultra-low insertion loss and high return loss, supporting stable long-distance high-bandwidth transmission. The small form factor LC interface doubles port density compared to SC connectors, making it ideal for high-density cabling in 1U/2U switch panels.

The duplex clip design holds two fibers together for easy plugging and polarity management. UPC physical polishing is standard; APC version is available for PON and CATV applications. PVC and LSZH low-smoke halogen-free jacket options meet different indoor installation and fire protection requirements. The reinforced anti-bending boot effectively protects the fiber root from damage caused by repeated plugging and bending.

Standard lengths from 1m to 30m are in stock. We support custom cable length, jacket material, polishing type and private-label packaging for bulk OEM & ODM orders, perfect for data center operators, system integrators and network equipment distributors.

LC to LC single-mode 9/125μm fiber, duplex design with clip
Small form factor for high-density cabling, ideal for SFP/SFP+ ports
Precision zirconia ceramic ferrules, low insertion loss & high return loss
UPC standard polishing; APC polishing available on request
PVC / LSZH flame-retardant jacket options
Reinforced anti-bending boot, durable for frequent plugging
Suitable for data center switch, 10G network, SAN storage, telecom transmission
Custom length, logo and packaging supported for bulk orders

Specifications

Item	Specification
Connector Type	LC Male to LC Male (Duplex)
Fiber Type	Single-Mode 9/125μm (SMF)
Ferrule Material	Zirconia Ceramic
Polishing	UPC (standard) / APC (optional)
Structure	Duplex with plastic clip
Insertion Loss	≤ 0.3dB (typical)
Return Loss	≥ 50dB (UPC) / ≥ 60dB (APC)
Jacket Material	PVC (standard) / LSZH (optional)
Jacket Color	Yellow (standard single-mode color)
Standard Length	1m, 2m, 3m, 5m, 10m, 15m, 20m, 30m
Compliance	RoHS, CE compliant
Application	SFP/SFP+ transceivers, data center switch, 10G Ethernet, SAN storage, high-density cabling
Custom Service	Custom length, polishing type, jacket material, logo printing, OEM packaging

FAQ

Q: Is this LC-LC cable compatible with SFP and SFP+ modules?

A: Yes, standard LC duplex interface fits all conventional SFP, SFP+ optical transceivers and fiber switch ports.

Q: What network speed does this single-mode fiber cable support?

A: The fiber itself supports Gigabit, 10G, 25G and even higher rates; the actual speed depends on the optical modules and equipment at both ends.

Q: What is the advantage of LC connector over SC?

A: LC is smaller in size, allowing twice the port density on switch panels, which is the mainstream choice for modern high-density data center cabling.

Q: Can I use this cable for 10G long-distance transmission?

A: Yes, single-mode 9/125μm fiber supports 10G transmission up to 10km, 20km and longer distances depending on the matching SFP+ module.

Q: Do you offer single-core simplex LC-LC cable?

A: Yes, both simplex and duplex structures are available. Please contact our sales for specific requirements.
